RATIO.pm6.5 - USA
Page 1.11
RATIO
BOGE – RATIO compressor control for screw compressors
Operation1.4
Operation RATIO
Press ↓-key a twelfth time → to return to the main
display. Press ↑-key - to watch the displays in the
reversed direction.
If no key is pressed for five minutes, the main
display automatically reappears.
Parameterization
of frequency converter
without running motor
Normally the converter is under tension as soon as the I-key (On) is pressed
and the compressor motor starts. In case the frequency converter has to be
parameterized during motor stand-still – you only have to press the ↵-key
– when the main display is shown – and the compressor is switched off.
Then the converter supply contactor starts up and the motor remains in stand-
still – the green LED is not illuminated.
By pressing the O-key (Off) the converter supply contactor drops out.
Operating/control element Function Operation/Explanation
