BOGE – RATIO compressor control for screw compressors
Control Parameterization1.5
Error key table
Each message is automatically
registered by the control, to-
gether with the associated time,
thus putting an overview at the
disposal of BOGE-Service.
1
) adjustable
Error Meaning Compr.-
No. cut-out
0 Compr. air treatment (dryer or condensate drain gives error message)
1
)
1 Final compression temperature > 110°C, 230°F X
2 Motor temperature too high X
3 Excessive current of vent. motor X
4 Incorrect direction of rotation X
5 Excessive compressor system pressure X
6 Excessive diff. pressure of intake filter
7 Excessive diff. pressure of oil filter
8 Excessive diff. pressure of oil separator
9 No output X
10 Motor servicing due
11 Compressor servicing due
12 System pressure decrease too slow
13 Frequency converter gives error message X
14 Temperature too low X
15
Suction control faulty (suction control or solenoid valve, if necessary clean
proportional controller)
16 Network pressure transmitter faulty X
System pressure increases too quickly (lack of oil, oil too old or even with
17 monitoring of the rotational direction a false rotational direction cannot be X
excluded)
18 Master control tries to go below P
min
– cf parameterization "External output enable"
Previous net switch-on phase was too short (possible reasons: coil short-circuit
19 'solenoid valve', 'delta contactor' or 'ventilator contactor') → automatically
increased delay time in corr. with permissible number of motor switch cycles
20 Master control tires to exceed P
max
– cf parameterization "External output enable"
21 Receiver or wearing parts inspection due
22 Not assigned here
23 Not assigned here
24 Not assigned here
25 Control unit Reconciliation error X
26 Control unit O-key does not open X
27 Control unit I-key does not open X
28 Control unit i-key does not open
29 Control unit ↵ -key does not open
30 Control unit "arrow up" does not open
31 Control unit "arrow down" does not open
32 Network pressure-transmitter wire breakage X
33 Compr.system pressure-transmitter wire breakage X
34 Compr.system pressure-transmitter faulty X
35 Excessive diff. pressure return valve
36 Bus Life-Bit did not toggle
38 Current of compressor motor is too high X
