Boge RATIO User Manual

RATIO.pm6.5 - USA
Page 1.4
RATIO
BOGE – RATIO compressor control for screw compressors
Operating/control element Function
The green indicator lamp indicates that the
machine is ready.
Lamp = red The red indicator lamp indicates a fault.Fault
Pressure gauge or target value (network).Network pressure
display
If parameterization has been started, this symbol
appears in the top left of the display.
Parameterization
Ready
Operation/Explanation
3-digit 7-segment display
P:
Shown in bar with a decimal point between the
second and third digit.
Displays:
Pressure
Lamp = green
3-digit 7-segment display
T:
In °C.Displays:
Temperature
Thermometer
Operating elements RATIO
Operating elements1.3
bar
°C
Compressed air parameterization start undergoing
parameterization or frost run = blinks.
Pressure gauge system pressure (compressor).System pressure
display
