Page 5.15
Maintenance
BOGE Operating instructions for S 40-2...S 341 / SF 40-2...SF 220 series screw compressors
DANGER: Risk of injury!
Danger of burning due to hot oil!
– Remove cladding on the maintenance side.
– Unscrew soiled oil separators by hand or use a strap wrench, turning
counterclockwise.
– Catch the draining oil and dispose of properly according to environmental
regulations.
– Lightly oil the sealing rings of the new oil separator.
– Screw in new oil separators by hand, turning clockwise.
CAUTION!
Do not use tools to screw in the new oil separators!
You might damage the oil separators or their sealing rings.
A hand tight seating of the oil separators is sufficient.
– Close safety sound insulation hood.
– Reattach cladding on the maintenance side.
– Open ball valve at the compressed air outlet.
– Switch on the compressor and heat up to operating temperature.
– Check the oil filter for leaks once again (Procedure as described above).
DANGER: Risk of injury!
Switch off the main switch and secure it against unintentional switch-on.
– Check the oil separators for leaks and tighten by hand, if necessary.
Fig. 5.9: Changing the oil separators Note:
5.3 Regular maintenance work
Note: Demonstration example. Compressor may only be operated with the switch cabinet
closed and all panels fitted.
