User Level Programming
View/Edit Schedule Change from the LCD Display
1) Type in the user level password (default is 1111) at the main screen tot enter user level programming.
2) Press the NO/CANCEL button until the display reads “View/Edit Schedule Change?” as shown in Fig 2.14.
3) The first schedule change will scroll across the top line of the LCD display as shown in Fig 2.15. Press the YES/ENTER button to edit the schedule
change.
4) To edit the schedule change, follow the steps on page 18.
5) To view the schedule changes, use the ↓ button to scroll between each one.
6) To exit and return to the main screen, continue to press the NO/CANCEL button until the main screen appears.
Activate Manually from the LCD Display
1) Type in the user level password (default is 1111) at the main screen to enter user level programming.
2) Press the NO/CANCEL button until the display reads “Activate Manually?” as shown in Fig 2.16.
3) Press the YES/ENTER button.
4) The display should look similar to Fig 2.17. To scroll through the zones, use the ↑ and ↓ buttons. To change the duration for a specific zone, use
the → button to change the duration.
5) To confirm the selection, press the YES/ENTER buttons. See Fig 2.18.
6) To exit and return to the main screen, continue to press the NO/CANCEL button until the main screen appears.
Fig 2.14
Fig 2.16
Fig 2.15
Fig 2.17
Fig 2.18
