Web Interface Programming
Add Programming/Countdown Mode
q
Schedule This field is where the user will enter which schedule they want the event to occur on.
w
Time These fields are where the user will enter the time in hour, minutes and seconds that the event is to occur.
e
Days These checkboxes, when checked, will determine what days of the week the event will occur on.
r
Zone Duration/Countdown These drop-down lists determine what duration the selected zone (relay) will close for, if any. There are five
options:
Option Description Miscellaneous Notes
N/A Not Applicable
On The zone (relay) will turn on.
Off The zone (relay) will turn off.
Configured Duration 1 The zone (relay) will turn on for the configured
duration which is set in the feature settings. Ranges from 1 - 3600 seconds.
Configured Duration 2 The zone (relay) will turn on for the configured
duration which is set in the feature settings. Ranges from 1 - 3600 seconds.
*CStart Starts the countdown feature. Countdown has an 18 hour time limit and cannot
proceed past midnight.
*CStop Stops the countdown feature. Countdown has an 18 hour time limit and cannot
proceed past midnight.
* This feature provides the Bogen digital clocks with the ability to count down from a preset amount of time. Simply enter a event with a CStart to start the timer and a
event with a CStop to stop the timer. The master clock will automatically calculate the difference in time between the CStart and CStop and will start counting down. There
must be an event with a CStart and an event with a CStop in order for this to function.
q
w
e
r
t y u
i o
To Next Page
