Indicators and Controls
BOMAG20 BPR 35/60
4.1 General notes
If you are not yet familiar with the control and dis-
play elements on this machine you should read
this section thoroughly before starting any opera-
tion on the machine. Here all functions are de-
scribed in detail.
The section "Operation" contains only brief de-
scriptions of the individual control steps.
4.2 Description of indicators
and control elements
Fig. 7
No. 1 = Steering rod height adjustment
No. 2 = Locking pawl lever
Fig. 8
No. 3 = Travel lever
No. 4 = Handle
No. 5 = Throttle lever
