Operation
BOMAG30 BPR 35/60
Fig. 29
l Close the fuel tap (Fig. 29) by turning in direc-
tion of arrow.
5.7 Assembling the transport
wheels
1
Danger
!
Danger of injury!
By the machine tipping over when assembling
or disassembling the transport wheels
Caution
!
Shut down the engine.
Fig. 30
l Adjust the steering rod upright and lock it. En-
gage the locking pawl lever securely.
l Remove the spring cotter (Fig. 30) and pull the
transport wheels out of the bracket on the
steering rod.
Fig. 31
l Stand at the side of the machine.
1 Optional equipment
690181
690180
