8.3
DISASSEMBLING A GEAR UNIT EQUIPPED WITH HOLLOW OUTPUT SHAFT
Unscrew the fixing screws gradually and then remove the shrink disc coupling
Now extract the machine’s shaft as described in heading 8.2.
8.4 SCRAPPING THE GEAR UNIT
This must only be done by operators trained in the observance of applicable laws on health and safety
at work.
Do not dump non-biodegradable products, lubricants and non-
ferrous materials (rubber, PVC, resins,
etc.) into the environment. Dispose of all such materials as stipulated by applicable environmental
protection legislation.
Do not attempt to re-
use parts or components which appear to be in good condition after they
have been checked and/or replaced by qualified personnel and declared unsuitable for use.
33
AND SHRINK DISC COUPLING
