gear unit may significantly alter the centre of gravity, thereby impairing the stability of the gear
unit.
In such cases it may be necessary to use an additional anchor point.
During lifting operations the load must not be allowed to swing beyond an arc of ± 15°.
If greater swinging movements occur during the procedure, stop and repeat the prescribed
operations in relation to the type of lifting system adopted.
12 ANNEX 3
12.1 CUSTOMER'S SHAFT series HDP
H
HDP 60
≥ 78
70 h6 69 283 56 172 220 30 20 h9 74.5 2.5 2 20 x 12 x 220A
HDP 70
≥ 89
80 h6 79 283 78 127 220 30 22 h9 85 2.5 2.5 22 x 14 x 220A
HDP 80
≥ 104
95 h6 94 338 73 192 280 30 25 h9 100 2.5 2.5 25 x 14 x 280A
HDP 90
≥ 121
110 h6 109 378 88 202 320 30 28 h9 116 2.5 2.5 28 x 16 x 320A
A1 A2 A3 B B1 B2 C D E F R S
UNI6604
S
HDP 60
≥ 90
72 h7 69 70 g6 328 59 194 2.5 2.5
HDP 70
≥ 104
82 h7 79 80 g6 332 77 174 2.5 2.5
HDP 80
≥ 119
97 h7 94 95 g6 398 95 205 2.5 2.5
HDP 90
≥ 136
112 h7 109 110 g6 440 87 273 2.5 2.5
A1 A2 A3 A4 B B1 B2 R S
37
