HDP 70
Rn
2
[kN]
n
2
xh
M
2
= 6350 Nm M
2
= 5050 Nm M
2
= 4200 Nm M
2
= 3150 Nm
250 000
35.2 40.0 37.2 40.0 38.1 40.0 39.2 40.0
32.8 40.0 34.8 40.0 36.1 40.0 37.8 40.0
500 000
25.1 34.5 28.9 37.0 30.1 37.9 31.2 39.0
24.8 32.7 26.8 34.7 28.1 36.0 29.7 37.6
750 000
20.0 28.5 23.9 32.1 26.1 33.1 27.2 34.2
20.8 27.9 22.8 29.8 24.2 31.1 25.8 32.7
1 000 000
16.5 24.6 20.7 28.3 23.2 30.0 24.7 31.1
17.8 24.8 20.3 26.7 21.6 28.0 23.2 29.6
1 250 000
13.0 21.8 18.4 25.5 20.9 27.7 22.9 28.8
15.1 22.5 18.4 24.5 19.8 25.8 21.4 27.4
2 500 000
— 12.7 11.2 18.0 14.6 20.5 17.7 22.8
— 14.7 12.6 18.5 14.8 19.7 16.5 21.3
3 750 000
— — — 14.1 11.4 16.7 14.6 19.7
— 10.0 — 15.1 12.2 16.7 14.0 18.3
5 000 000
— — — 11.0 — 14.3 12.7 17.3
— — — 12.3 — 14.8 12.4 16.4
HDP 70
Rn
2
[kN]
n
2
xh
M
2
= 6350 Nm M
2
= 5050 Nm M
2
= 4200 Nm M
2
= 3150 Nm
250 000
26.0 35.7 29.4 39.1 31.6 40.0 34.4 40.0
23.1 32.8 27.1 36.8 29.7 39.4 33.0 40.0
500 000
18.0 25.9 21.4 29.3 23.6 31.5 26.4 34.2
15.1 23.0 19.1 27.0 21.7 29.6 25.0 32.8
750 000
14.0 21.0 17.4 24.4 19.7 26.6 22.4 29.3
11.1 18.1 15.1 22.1 17.7 24.7 21.0 27.9
1 000 000
11.4 17.9 14.9 21.3 17.1 23.5 19.9 26.2
— 15.0 12.6 19.0 15.2 21.6 18.4 24.8
1 250 000
— 15.7 13.0 19.1 15.3 21.3 18.0 24.0
— 12.8 10.7 16.8 13.4 19.4 16.6 22.6
2 500 000
— 9.7 — 13.0 10.3 15.2 13.1 18.0
— — — 10.7 — 13.3 11.7 16.5
3 750 000
— — — 10.0 — 12.2 10.6 15.0
— — — — — 10.3 — 13.5
5 000 000
— — — 8.1 — 10.3 — 13.0
— — — — — 8.4 — 11.6
Carichi radiali ammissibili relativi ai cusci
-
netti secondo variante HDB.
Albero al quale sono riferiti i carichi radiali
ammissibili. Per gli alberi bisporgenti il cari
-
co può essere applicato solo sull’estremità
così evidenziata. In caso diverso consultare
il Servizio Tecnico Bonfiglioli.
Rated overhung loads relevant to rein
-
forced bearings type HDB.
Zulässige Radialkräfte der Lager gemäß
Variante HDB.
Welle, auf die sich die zulässigen Radialkräfte
beziehen. Für die Wellen mit zwei Wellenzap
-
fen kann die Kraft nur auf das so gekenn
-
zeichnete Wellenende ausgeübt werden. An
-
dernfalls mit dem technischen Kundendienst
von Bonfiglioli Rücksprache halten.
h: durata in ore riferita al cuscinetto dell'albero
lento.
h: expected lifetime [hours] for bearing of the
output shaft.
h: Lebensdauer in Stunden für das Lager der
Abtriebswelle.
Shaft the rated overhung load is applicable to.
For double extended shaft the load is only ap
-
plicable to the extension highlighted Should
this not be the case consult Bonfiglioli’s Tech
-
nical Service.
(—) Consultare il Servizio Tecnico Bonfiglioli (—) Contact the Bonfiglioli Technical Service. (—) Bitte wenden Sie sich an den technischen
Kundendienst von Bonfiglioli.
