h: durata in ore riferita al cuscinetto dell'albero
lento.
h: expected lifetime [hours] for bearing of the
output shaft.
h: Lebensdauer in Stunden für das Lager der
Abtriebswelle.
(—) Consultare il Servizio Tecnico Bonfiglioli (—) Contact the Bonfiglioli Technical Service. (—) Bitte wenden Sie sich an den technischen
Kundendienst von Bonfiglioli.
I carichi radiali ammissibili indicati nelle ta
-
belle soprastanti si riferiscono al caso di
forze applicate dal lato evidenziato in figura.
Die zuverlässige Radialkräfte in o. g. Ta
-
bellen sind für Kräfte an der Zeichnungs
-
seite ausgezeichnet gültig.
Rated overhung loads charted above refer to
the case of forces applying on the side
shown in the picture.
HDP 150
Rn
2
[kN]
n
2
xh M
2
= 96250 Nm M
2
= 77000 Nm M
2
= 64150 Nm M
2
= 48100 Nm
250 000
200.0 200.0 200.0 200.0
200.0 200.0 200.0 200.0
500 000
164.5 194.2 200.0 200.0
165.5 180.2 190.1 200.0
750 000
126.9 158.9 176.0 185.0
136.7 152.8 162.7 175.0
1 000 000
102.2 135.6 155.5 167.4
108.6 135.3 145.2 157.4
1 250 000
83.7 118.6 139.2 154.9
87.8 122.8 132.6 144.8
2 500 000
— 70.3 93.6 119.0
— 74.2 98.5 110.8
3 750 000
— — 69.9 97.1
— 44.1 74.3 93.8
5 000 000
— — 53.9 82.7
— — 56.5 83.0
HDP 150
Rn
2
[kN]
n
2
xh M
2
= 96250 Nm M
2
= 77000 Nm M
2
= 64150 Nm M
2
= 48100 Nm
250 000
174.0 198.2 200.0 200.0
152.5 181.0 199.9 200.0
500 000
118.7 142.9 159.0 179.0
97.2 125.7 144.6 168.3
750 000
91.3 115.4 131.5 151.7
69.9 98.2 117.3 140.9
1 000 000
73.7 97.9 114.0 134.1
52.3 80.8 99.7 123.4
1 250 000
61.1 85.3 101.4 121.5
— 68.2 87.1 110.8
2 500 000
— 51.1 67.2 87.4
— — 53.0 76.7
3 750 000
— — 50.3 70.4
— — — 59.8
5 000 000
— — — 59.6
— — — 48.9
SH
4x
3x
2x
4x
3x
2x
SH
