BONFIGLIOLI HDP Series User Manual

129
Albero al quale sono riferiti i carichi radiali
ammissibili. Per gli alberi bisporgenti il cari
-
co può essere applicato solo sull’estremità
così evidenziata. In caso diverso consultare
il Servizio Tecnico Bonfiglioli.
Welle, auf die sich die zulässigen Radialkräfte
beziehen. Für die Wellen mit zwei Wellenzap
-
fen kann die Kraft nur auf das so gekenn
-
zeichnete Wellenende ausgeübt werden. An
-
dernfalls mit dem technischen Kundendienst
von Bonfiglioli Rücksprache halten.
h: durata in ore riferita al cuscinetto dell'albero
lento.
h: expected lifetime [hours] for bearing of the
output shaft.
h: Lebensdauer in Stunden für das Lager der
Abtriebswelle.
Shaft the rated overhung load is applicable to.
For double extended shaft the load is only ap
-
plicable to the extension highlighted Should
this not be the case consult Bonfiglioli’s Tech
-
nical Service.
(—) Consultare il Servizio Tecnico Bonfiglioli (—) Contact the Bonfiglioli Technical Service. (—) Bitte wenden Sie sich an den technischen
Kundendienst von Bonfiglioli.
HDP 160
Rn
2
[kN]
n
2
xh M
2
= 123200 Nm M
2
= 98550 Nm M
2
= 82100 Nm M
2
= 61600 Nm
250 000
135.0 175.2 192.8 204.9
143.7 163.3 176.2 192.5
500 000
65.4 112.3 139.4 159.6
68.1 118.0 130.9 147.2
750 000
— 78.9 108.1 137.2
— 84.7 108.5 124.7
1 000 000
— 56.6 87.6 120.7
— 58.5 94.2 110.4
1 250 000
— — 72.5 107.0
— — 77.8 100.0
2 500 000
— — — 67.8
— — — 72.2
3 750 000
— — — 47.1
— — — 50.5
5 000 000
————
————
HDP 160
Rn
2
[kN]
n
2
xh M
2
= 123200 Nm M
2
= 98550 Nm M
2
= 82100 Nm M
2
= 61600 Nm
250 000
106.2 133.3 151.3 173.8
79.7 112.0 133.7 160.5
500 000
57.3 87.8 106.0 128.5
— 66.4 88.2 115.2
750 000
— 65.4 83.5 106.0
— 44.2 65.8 92.7
1 000 000
— 50.1 69.2 91.6
— — 51.5 78.3
1 250 000
— — 58.8 81.4
— — — 68.1
2 500 000
— — — 53.4
————
3 750 000
————
————
5 000 000
————
————
4x
3x
2x
4x
3x
2x
LP
LP
