BONFIGLIOLI HDP Series User Manual

169
M M1 M2 N N1 N2 N3 N4 X P
HDP 100_112
28 31.3 8 250 215 180 15 14 5 395
HDP 100_132
38 41.3 10 300 265 230 — M12x20 6 415
HDP 100_160
42 45.3 12 350 300 250 23 18 6 481
HDP 100_180
48 51.8 14 350 300 250 23 18 6 481
HDP 100_200
55 59.3 16 400 350 300 — M16x23 7 506
HDP 100_225
60 64.4 18 450 400 350 26 18 7 513
HDP 100_250
65 69.4 18 550 500 450 30 18 6 543
HDP 100_280
75 79.9 20 550 500 450 30 18 6 543
HDP 100_315
80 85.4 22 660 600 550 22 22 10 579.5
HDP 110_112
28 31.3 8 250 215 180 15 14 5 395
HDP 110_132
38 41.3 10 300 265 230 — M12x20 6 415
HDP 110_160
42 45.3 12 350 300 250 23 18 6 481
HDP 110_180
48 51.8 14 350 300 250 23 18 6 481
HDP 110_200
55 59.3 16 400 350 300 — M16x23 7 506
HDP 110_225
60 64.4 18 450 400 350 26 18 7 513
HDP 110_250
65 69.4 18 550 500 450 30 18 6 543
HDP 110_280
75 79.9 20 550 500 450 30 18 6 543
HDP 110_315
80 85.4 22 660 600 550 22 22 10 579.5
HDP 120_132
38 41.3 10 300 265 230 — M12x20 6 430
HDP 120_160
42 45.3 12 350 300 250 23 18 6 496
HDP 120_180
48 51.8 14 350 300 250 23 18 6 496
HDP 120_200
55 59.3 16 400 350 300 — M16x23 7 521
HDP 120_225
60 64.4 18 450 400 350 26 18 7 528
HDP 120_250
65 69.4 18 550 500 450 30 18 6 558
HDP 120_280
75 79.9 20 550 500 450 30 18 6 558
HDP 120_315
80 85.4 22 660 600 550 22 22 10 594.5
