M M1 M2 N N1 N2 N3 N4 X P
HDP 130_160
42 45.3 12 350 300 250 23 18 6 551
HDP 130_180
48 51.8 14 350 300 250 23 18 6 551
HDP 130_200
55 59.3 16 400 350 300 — M16x23 7 576
HDP 130_225
60 64.4 18 450 400 350 26 18 7 583
HDP 130_250
65 69.4 18 550 500 450 30 18 6 613
HDP 130_280
75 79.9 20 550 500 450 30 18 6 613
HDP 130_315
80 85.4 22 660 600 550 22 22 10 649.5
HDP 140_160
42 45.3 12 350 300 250 23 18 6 551
HDP 140_180
48 51.8 14 350 300 250 23 18 6 551
HDP 140_200
55 59.3 16 400 350 300 — M16x23 7 576
HDP 140_225
60 64.4 18 450 400 350 26 18 7 583
HDP 140_250
65 69.4 18 550 500 450 30 18 6 613
HDP 140_280
75 79.9 20 550 500 450 30 18 6 613
HDP 140_315
80 85.4 22 660 600 550 22 22 10 649.5
HDP 150_160
42 45.3 12 350 300 250 23 18 6 601
HDP 150_180
48 51.8 14 350 300 250 23 18 6 601
HDP 150_200
55 59.3 16 400 350 300 — M16x23 7 626
HDP 150_225
60 64.4 18 450 400 350 26 18 7 633
HDP 150_250
65 69.4 18 550 500 450 30 18 6 663
HDP 150_280
75 79.9 20 550 500 450 30 18 6 663
HDP 150_315
80 85.4 22 660 600 550 22 22 10 699.5
HDP 160_160
42 45.3 12 350 300 250 23 18 6 601
HDP 160_180
48 51.8 14 350 300 250 23 18 6 601
HDP 160_200
55 59.3 16 400 350 300 — M16x23 7 626
HDP 160_225
60 64.4 18 450 400 350 26 18 7 633
HDP 160_250
65 69.4 18 550 500 450 30 18 6 663
HDP 160_280
75 79.9 20 550 500 450 30 18 6 663
HDP 160_315
80 85.4 22 660 600 550 22 22 10 699.5
