Borri E2001 COMPACT - Figure 1 - Front Panel

Front panel AC-UPS GD 128x64
6 OMX76014 Rev. A
3. FRONT PANEL
The front panel of the rectifier is composed of an alphanumerical graphic display, 20
configurable LEDs and 7 function keys that allow navigation. A synoptic display shows
the functional status of the device and the power flow.
Figure 1 – Front panel
