Front panel AC-UPS GD 128x64
OMX76014 Rev. A 11
INVERTER
Inverter output voltage
(1)
1 V
Inverter output current
1 A
Inverter output frequency
0.1 Hz
BYPASS
Bypass output voltage
(1)
1 V
Bypass output frequency
0.1 Hz
OUTPUT
Output voltage
(1)
1 V
Output current
1 A
Output frequency
0.1 Hz
(1) This voltage measurement refers to the value between the phases
(2) The battery measurements are only displayed for configuration with at least one battery installed.
(3) The measurements are only available for the configuration with 2 batteries installed.
(4) The measurements are only available for the configuration with 3 batteries installed.
(5) The residual energy is only available on special request
(6) The temperatures are only displayed with at least one probe installed
(7) Only the probes installed are displayed
