Front panel AC-UPS GD 128x64
14 OMX76014 Rev. A
4.2.2 Battery test commands
The UPS can give commands to execute the following battery tests (where
available):
Request boost: forces the machine in Boost mode for 60 seconds; after this
interval if the amperometric relay does not intervene the machine returns to
buffer mode.
Forced boost: the machine is in Boost mode for the entire time set in eeprom.
Manual charging: executes a manual charge cycle.
Rapid recharge test: increase the output voltage of the rectifier from buffer
float charge up to rapid recharge, monitoring the battery current.
Flat battery rapid test: decrease the output voltage from the buffer float charge
up to the second level of battery minimum voltage, monitoring the battery
current.
Flat battery manual test: allows the user to choose the minimum voltage level
of the battery test and its duration; during the output voltage test of the rectifier,
it will be set at 1V under the minimum voltage level of the battery test. The test
will be exceeded if for its entire duration the voltage of the battery does not go
under the minimum test level.
Another type of test is available, the flat battery automatic test; this test, being
automatic, does not need any command in the setting menu, you can however
choose the date and time from the two consecutive tests.
Further information
For further information on the battery test, consult the device manual.
