Fan Motor Options
14.3.1 Constant Airflow Motors Performance Data—Vertical Configuration
Table 14 Constant Airflow Motors Performance Data—Vertical Configuration
Model Fan Speed
Default
Factory
Motor
Setting
CFM
0.10 0.20 0.30 0.40 0.50 0.60 0.70 0.80 0.90 1.00 1.10 1.20
CL015
D—Low 460 460 460 460 460 460 460 440 410 390 — —
D—Normal X 550 550 550 550 550 550 550 550 550 550 — —
D—High 610 620 640 640 640 640 640 640 620 590 — —
CL018
A—Low 510 510 510 510 510 510 510 500 480 460 — —
A—Normal X 600 600 600 600 600 600 600 580 540 500 — —
A—High 685 685 685 685 685 685 640 600 560 520 — —
CL024
A— Low 680 680 680 680 680 680 680 680 650 620 — —
A—Normal X 800 800 800 800 800 800 800 780 740 680 — —
A—High 900 900 900 900 900 900 900 870 840 710 — —
CL030
C—Low 810 830 830 830 830 830 830 830 — — — —
C—Normal X 930 950 950 950 950 950 950 900 — — — —
C—High 1040 1040 1040 1040 1040 1020 980 940 — — — —
CL036
A—Low 1020 1040 1040 1040 1040 1040 1040 1040 1020 1000 — —
A—Normal X 1200 1200 1200 1200 1200 1200 1200 1160 1140 1060 — —
A—High 1160 1200 1280 1300 1300 1340 1380 1380 1380 1380 — —
CL042
A—Low 1180 1200 1200 1200 1200 1200 1200 1200 1200 1200 — —
A—Normal X 1340 1400 1400 1400 1400 1400 1400 1400 1400 1400 — —
A—High 1520 1530 1550 1550 1550 1550 1550 1550 1550 1580 — —
CL048
B—Low 1350 1350 1350 1350 1350 1350 1350 1350 1350 1350 — —
B—Normal X 1600 1600 1600 1600 1600 1600 1600 1600 1600 1600 — —
B—High 1750 1750 1750 1750 1750 1750 1780 1800 1800 1800 — —
CL060
C—Low 1700 1725 1725 1725 1725 1725 1725 1725 1725 1700 — —
C—Normal X 2000 2000 2000 2000 2000 2000 2000 2000 2000 2000 2000 2000
C—High 2260 2260 2260 2260 2260 2260 2260 2260 2200 2160 2120 2080
CL070
A—Low 1800 1800 1800 1800 1800 1800 1800 1800 1800 1800 1800 1800
A—Normal X 2100 2100 2100 2100 2100 2100 2100 2100 2100 2100 2100 2100
A—High 2375 2375 2375 2375 2375 2375 2375 2375 2375 2375 2300 2270
