Bosch D6600 - 8.0 Standby Power; 8.1 Connecting External Batteries

D6600 | Operation and Installation Guide | 8.0 Standby Power
14 Bosch Security Systems | 2/05 | 4998122704E
8.1 Connecting External Batteries
Do not connect an external battery
charger to the D6600.
Use the terminal on the rear panel to connect an
external DC power source. During AC power outages,
the external DC source supplies power to the receiver.
Use a 12 VDC lead-acid battery for external back-up
power.
Only use approved stationary standby batteries for UL
applications. Battery wiring must run from the receiver
through the UL Listed rack, exit the rack through a
conduit connection, and terminate at a UL Listed
battery enclosure suitable for the size and number of
batteries used for UL applications.
Table 5: Battery Voltage Display
Battery Voltage Display (during
AC power
outage)
Display (if
battery missing
when AC power
restores)
11.5 V above
Battery OK
11.5 V to 10.2 V
Battery Low
Below 10.2 V
Battery Bad
Battery
Missing
Table 6 shows the calculations for the standby capacity
required by UL when using the D6600.
Table 6: Calculating Standby Capacity Required by UL
Device Qty Battery Standby
Current
Total Battery
Standby Current
UPS Standby
Current
Total UPS
Standby Current
D6600 Base with one D6640/ D6641
installed
1 800 mA 800 mA 350 mA 350 mA
D6640/ D6641 Line Cards (up to 8) 210 mA/each 35 mA/each
D6672 COM1 Adapter 10 mA 2 mA
Total: Total:
8.1.1 Minimum Standby Battery Chart
Table 7 shows the derated battery divided by the hours.
Derated battery = Battery Ah - 20% Storage
8.1.2 Minimum Standby UPS Power
Total UPS current x 120 (voltage) x desired hours of
standby + 20% (storage) = Minimum UPS required in
watts.
Table 7: Minimum Standby Battery Chart
Rechargeable Battery
Size
Maximum Standby for 4 hr
7 Ah 1400 mA
8 Ah 1600 mA
10 Ah 2000 mA
12 Ah 2400 mA
18 Ah 3440 mA
