2. Turn the Battery Pack to top view (1) and hook the securing nocks (6) in the Wireless
Device battery compartment.
3. Gently push down the Battery Pack until it locks (2) into the Wireless Device Battery Pack
compartment.
How to remove the Battery Pack
1. Turn the Wireless Device up‑side‑down.
2. Remove the Battery Pack in reverse order by push‑and‑hold the locking clip (2) and gently
pushing up the Battery Pack.
3. Take out the Battery Pack.
Connections and indicators
The following table gives an overview of the Battery Pack connections and indicators (refer to
the numbers in the previous figure in this section).
Item
Description
1 Top view.
2 Locking clip mechanism: Locks the Battery Pack in the Wireless Device.
3 Rear view.
4 Battery Pack capacity/condition test button: Pushing the button lights 0 to 5
capacity LED indicators, depending on the capacity time left (5).
5 Green Battery Pack capacity LED indicators (5x): Showing the capacity/
condition of the Battery Pack. From left to right (5‑1), typical each LED indicates
a capacity time in hours left:
– LED 5: 18‑20
– LED 4: 13‑18
– LED 3: 8‑13
– LED 2: 3‑8
– LED 1: <3
NOTE: The accuracy of the Battery Pack remaining capacity is +/- 20%.
6 Securing nock (3x). Secures the Battery Pack in the Wireless Device.
7 Power supply and charging connector.
24
