Microphones
9
Figure 6.1: DCNM‑HDMIC or DCNM‑MICx to Wireless Device connection
Both the DCNM‑HDMIC High Directive Microphone and DCNM-MICL/S Stem Microphone are
typically used with the DCN multimedia device and DICENTIS wireless devices.
3
6
4
7
1
2
5
8
3
6
4
7
1
2
5
8
Figure 6.2: DCNM‑HDMIC and DCNM‑MICx front and bottom view
Number
Description
1 LED indicator.
2 Microphone grill (DCNM‑MICx or left and right DCNM‑HDMIC).
3 Microphone grill (front and rear DCNM‑HDMIC).
3 Adjustable stem (DCNM‑MICx).
6.1
