5.2 Mouse Controls
All functions controlled by the front panel can, alternatively, be accessed using a USB mouse.
All main DVR functions are accessible via the System Control Bar. To display the panel
(monitor A only), move the mouse pointer to the bottom left of the screen or press the menu
key. To close the System Control Bar press the exit key.
Figure 5.3 System Control Bar
The buttons and indicators of the System Control Bar work the same as the keys and
indicators on the front panel.
– The System Control Bar can also be controlled with the Arrow Keys and Enter Key.
5.3 Remote control
All functions controlled by the front panel and USB mouse can, alternatively, be accessed
using the supplied remote control. The IR remote control allows control of up to nine units
without interfering with one another.
An ID number must be set on the remote control and in the system. See Section 6.6.7 System,
Page 74 for setting the system ID for the unit.
To set the ID on the remote control:
1. Press the ID button on the remote control.
2. Press a number between 1 and 9 that corresponds to the unit ID you wish to control.
Figure 5.4 Remote control
