Digital Video Recorder 440/480 Series Configuration menu | en 59
Bosch Security Systems Installation and Operation manual AM18-Q0605 | v2.0 | 2012.04
Table 6.5 Maximum Frame Rates (PAL/NTSC IPS) by Resolutions for enabled Channels (8)
6.1.10 Video format
Figure 6.9 Camera - Video format
Select the Video format, NTSC, PAL, or Auto detect, that the unit will operate with. When set
to Auto detect, the format during startup of the video on the first channel where video is
connected will be used to set the DVR to either PAL or NTSC.
Select the VGA Output to match the best VGA resolution on the used VGA monitor
(monitor A).
Channels Enabled (8) CIF
8 6.25/7.5
7 6.25/7.5
6 6.25/7.5
5 6.25/7.5
4 12.5/15
3 12.5/15
2 25/30
1 25/30
