Bosch DVR 440 - 6.1.2 Maximum Frame Rates DVR 440; 6.1.3 Maximum Frame Rates DVR 480; 6.1.4 Video Adjustment

Digital Video Recorder 440/480 Series Configuration menu | en 53
Bosch Security Systems Installation and Operation manual AM18-Q0605 | v2.0 | 2012.04
6.1.2 Maximum frame rates DVR 440
Table 6.2 Maximum Frame Rates (PAL/NTSC IPS) by Resolutions for enabled Channels
6.1.3 Maximum frame rates DVR 480
Table 6.3 Maximum Frame Rates (PAL/NTSC IPS) by Resolutions for enabled Channels
6.1.4 Video adjustment
Figure 6.3 Camera - Video adjustment
Channel
Select the camera channel for adjustment. The preview displays the channel indicated.
Channels Enabled CIF 2CIF 4CIF
4 25/30 25/30 12.5/15
3 25/30 25/30 12.5/15
2 25/30 25/30 25/30
1 25/30 25/30 25/30
Channels Enabled CIF 2CIF 4CIF
8 25/30 12.5/15 6.25/7.5
7 25/30 12.5/15 6.25/7.5
6 25/30 12.5/15 6.25/7.5
5 25/30 12.5/15 6.25/7.5
4 25/30 25/30 12.5/15
3 25/30 25/30 12.5/15
2 25/30 25/30 25/30
1 25/30 25/30 25/30
