58 en | Configuration menu Digital Video Recorder 440/480 Series
AM18-Q0605 | v2.0 | 2012.04 Installation and Operation manual Bosch Security Systems
6.1.9 Network Live Streaming
Figure 6.8 Camera - Network Live Streaming
Use the same procedure as Continuous Recording to set the values for cameras that will be
streamed over the network.
– Network Streams are not recorded.
– Network Streaming performance is limited by the total bandwidth between the unit and
the PC running the Web-based control application.
Note:
Disabling channels will allow increasing the frame rate on the remaining enabled channels.
Table 6.4 Maximum Frame Rates (PAL/NTSC IPS) by Resolutions for enabled Channels (4)
Channels Enabled (4) CIF
4 12.5/15
3 12.5/15
2 25/30
1 25/30
