Bosch DX025 - Performance Tables; Full Load Y1 + Y2 Blower Performance - DX Units; Part Load Y1 Blower Performance - DX Units



Subject to change without prior notice Revised 11-11
6720220327

MODEL
NOMINAL
TONS
MOTOR
HP
VOLTS, 1
PH 50/60
HZ
BLOWER
WHEEL
JUMPER
CFM
@
0.1"
CFM
@
0.2"
CFM
@
0.3"
CFM
@
0.4"
CFM
@
0.5"
CFM
@
0.6"
CFM
@
0.7"
CFM
@
0.8"
CFM
@
0.9"
CFM
@
1.0"
DX025 2 1/3 240 9X6
A 993 993 993 993 993 993 974 953 921 610
B 954 954 954 954 954 954 954 906 878 436
C 877 877 877 877 877 877 877 863 782 436
D 767 767 767 767 767 767 767 767 643 620
DX035 3 1/2 240 10X7
A 1556 1556 1556 1556 1556 1556 1528 1508 1479 1448
B 1547 1547 1547 1547 1547 1547 1528 1498 1469 1448
C 1275 1275 1275 1275 1275 1275 1275 1275 1275 1275
D 1124 1124 1124 1124 1124 1121 1116 1110 1099 1088
DX049 4 3/4 240 12X9
A 2325 2325 2325 2297 2255 2212 2169 2139 2109 2064
B 2255 2255 2255 2255 2227 2227 2184 2139 2109 2079
C 2048 2048 2048 2048 2048 2048 2033 2033 2017 2017
D 1920 1920 1920 1920 1920 1920 1904 1904 1887 1870
DX061
DX071
5 & 6 1 240 12X10
A 2566 2566 2566 2518 2505 2481 2431 2406 2381 2355
B 2549 2549 2549 2513 2489 2464 2426 2401 2375 2336
C 2537 2537 2537 2537 2513 2476 2451 2413 2375 2336
D 2525 2525 2525 2501 2476 2451 2413 2388 2349 2323

MODEL
NOMINAL
TONS
MOTOR
HP
VOLTS, 1
PH 50/60
HZ
BLOWER
WHEEL
JUMPER
CFM
@
0.1"
CFM
@
0.2"
CFM
@
0.3"
CFM
@
0.4"
CFM
@
0.5"
CFM
@
0.6"
CFM
@
0.7"
CFM
@
0.8"
CFM
@
0.9"
CFM
@
1.0"
DX025 2 1/3 240 9X6
A 849 849 849 849 849 849 849 841 600 600
B 754 754 754 754 754 746 726 726 718 412
C 692 692 692 692 692 683 679 670 670 400
D 598 598 598 598 598 598 580 580 580 574
DX035 3 1/2 240 10X7
A 1438 1438 1438 1438 1438 1438 1438 1438 1428 1417
B 1227 1227 1227 1227 1227 1227 1227 1227 1227 1215
C 955 955 955 955 955 955 955 955 941 928
D 844 844 844 844 832 844 837 829 815 808
DX049 4 3/4 240 12X9
A 2169 2169 2169 2169 2169 2169 2154 2139 2109 2064
B 1747 1747 1747 1747 1747 1747 1747 1729 1729 1710
C 1575 1575 1575 1575 1575 1575 1575 1575 1575 1575
D 1492 1492 1492 1492 1492 1492 1492 1492 1492 1470
DX061
DX071
5 & 6 1 240 12X10
A 2474 2474 2474 2474 2456 2415 2391 2354 2335 2304
B 2305 2305 2305 2305 2298 2292 2292 2279 2273 2266
C 2106 2106 2106 2106 2106 2099 2099 2099 2099 2092
D 1895 1895 1895 1895 1887 1879 1879 1879 1879 1879

