HP
Amps
(1)
# of
Circuits
kW
Amps
208 V
Amps
208 V
Amps
240 V
Amps
240 V
MCA
208 V
MCA
208 V
MCA
240 V
MCA
240 V
MOCP
208 V
MOCP
208 V
MOCP
240 V
MOCP
240 V
Cr1 Cr2 Cr1 Cr2 Cr1 Cr2 Cr1 Cr2 Cr1 Cr2 Cr1 Cr2
1/3 0.78
0 0 - - - - 1.0 - 1.0 - 10 - 10 -
1 5 18.0 - 20.8 - 23.3 - 26.8 - 35 - 35 -
1 10 36.1 - 41.7 - 45.9 - 52.9 - 50 - 60 -
1/2 2.03
0 0 - - - - 2.5 - 2.5 - 10 - 10 -
1 5 18.0 - 20.8 - 24.6 - 28.1 - 35 - 40 -
1 10 36.1 - 41.7 - 47.1 - 54.1 - 60 - 60 -
2 15 18.0 36.1 20.8 41.7 24.5 47.2 28.0 54.2 30 50 35 60
3/4 2.5
0 0 - - - - 3.1 - 3.1 - 15 - 15 -
1 5 18.0 - 20.8 - 25.0 - 28.5 - 35 - 40 -
1 10 36.1 - 41.7 - 47.6 - 54.6 - 60 - 70 -
2 15 18.0 36.1 20.8 41.7 25.0 47.6 28.5 54.6 30 50 30 60
2 20 36.1 36.1 41.7 41.7 47.6 47.6 54.6 54.6 50 50 60 60
1 3.8
0 0 - - - - 4.7 - 4.7 - 15 - 15 -
1 5 18.0 - 20.8 - 26.3 - 29.8 - 35 - 40 -
1 10 36.1 - 41.7 - 48.8 - 55.8 - 60 - 70 -
2 15 18.0 36.1 20.8 41.7 26.3 48.9 29.8 55.9 30 50 35 60
2 20 36.1 36.1 41.7 41.7 48.9 48.9 55.9 55.9 50 50 60 60
(1) = Rated Motor Amps @0.3” ESP (DOE External Static Rating Point)
