Bosch DX025 - Motor Control Board; Paired with TA Condensing Section; Paired with CE Condensing Section



6720220327
Revised 11-11 Subject to change without prior notice
UNIT
PAIRED WITH TA CONDENSING SECTION PAIRED WITH CE CONDENSING SECTION
PART
LOAD
AIR
FLOW
FULL
LOAD
AIR
FLOW
MOTOR
BOARD
JUMPERS
SETTING FOR
NORMAL
OPERATION
ADJUSTMENT
SETTING
(“NORM”, “+”, OR “-”)
PART
LOAD
AIR
FLOW
FULL
LOAD
AIR
FLOW
MOTOR
BOARD
JUMPERS
SETTING FOR
NORMAL
OPERATION
ADJUSTMENT
SETTING
(“NORM”, “+”, OR “-”)
DX025 750 950 JUMPER "B" "NORM" 500 800 JUMPER "D" "NORM"
DX035 1000 1200 JUMPER "C" "NORM" 800 1200 JUMPER "C" "NORM"
DX049 1300 1700 JUMPER "D" "NORM" 1000 1600 JUMPER "D" "-"
DX061 1500 2000 JUMPER "D" "NORM" 1400 2000 JUMPER "D" "-"
DX071 1500 2200 JUMPER "D" "NORM" 1400 2200 JUMPER "D" "-"

