Bosch DX025 - Physical Data



6720220327
Revised 11-11 Subject to change without prior notice

Table 1: Physical Data
DX UNITS
DX025 DX035 DX049 DX061 DX071
Nominal Capacity (Tons)
2 3 4 5 6
Refrigerant Type
R410A
Liquid Line Connection Size (in)
3/8 3/8 3/8 3/8 3/8
Suction Line Connection Size (in)
3/4 3/4 7/8 7/8 7/8
Standard Filter Size
16 x 20 x 2 20 x 20 x 2 20 x 24 x 2 20 x 24 x 2 20 x 24 x 2
Condensate Connection Size (in)
3/4 3/4 3/4 3/4 3/4
Blower Size
9X6 10X7 12X9 12X10 12X10
Blower Motor HP
1/3 1/2 3/4 1 1
Blower Motor Type ECM Style - Constant CFM/Variable Speed
Available Electrical (v/p/h) 208-230 / 1 / 60
Shipping Weight (lbs)
120 145 202 212 217
Installation Weight (lbs)
108 132 170 172 180
HY025 HY035 HY049 HY061 HY071
Nominal Capacity (Tons)
2 3 4 5 6
Water In Connection Size (in)
7/8 7/8 1-1/8 1-1/8 1-1/8
Standard Filter Size
16 x 20 x 2 20 x 20 x 2 20 x 24 x 2 20 x 24 x 2 20 x 24 x 2
Condensate Connection Size (in)
3/4 3/4 3/4 3/4 3/4
Blower Size
9X6 10X7 12X9 12X10 12X10
Blower Motor HP
1/3 1/2 3/4 1 1
Blower Motor Type ECM Style - Constant CFM/Variable Speed
Available Electrical (v/p/h) 208-230 / 1 / 60
Shipping Weight (lbs)
130 145 215 215 218
Installation Weight (lbs)
110 132 184 184 184
