Bosch EC Series - Specification Tables; Blower Performance Table

Specification Tables
19 Specification Tables
19.1 Blower Performance Table
Key for the Table Below:
Standard RPM Range
5 HP required due to the RPM range or ETO for smaller HP motor with different pulleys.
Outside the RPM range with standard pulley. ETO required.
Outside the manufacturer’s recommended operating range or outside the offered HP.
NOTICE
Contact Engineering Applications if additional airflow values
are needed.
NOTICE
Brake Horsepower (BHP) values shown are based on system
requirements, not the individual blower.
Models CFM
Available External Static Pressure (in.wg Wet Coil and Standard Filter 1” MERV5)
0.2 0.4 0.6 0.8 1 1.2 1.4 1.6 1.8 2
RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP
EC072
2,000 606 0.35 693 0.43 774 0.52 850 0.62
2,500 706 0.61 780 0.72 850 0.82 916 0.93 979 1.04 1040 1.16 1098 1.28
3,000 814 1.00 877 1.12 938 1.24 996 1.37 1053 1.50 1107 1.63 1160 1.76 1211 1.90
3,500 923 1.52 979 1.66 1033 1.80 1085 1.94 1135 2.09 1184 2.24 1232 2.39 1279 2.54
4,000 1033 2.20 1083 2.36 1131 2.52 1178 2.68
EC096
2,000 685 0.43 766 0.51 843 0.61 915 0.71
2,500 695 0.6 769 0.7 839 0.81 906 0.91 970 1.03 1031 1.14 1090 1.27
3,000 801 0.97 865 1.09 926 1.22 985 1.34 1042 1.47 1096 1.6 1149 1.74 1201 1.88
3,500 906 1.48 962 1.62 1017 1.76 1069 1.90 1120 2.05 1170 2.19 1218 2.34 1265 2.5
4,000 1016 2.14 1066 2.30 1115 2.46 1162 2.62
EC120 VT
2,500 625 0.58 692 0.70
3,000 661 0.80 723 0.94 780 1.08 835 1.22
3,500 650 0.97 709 1.11 765 1.26 818 1.41 869 1.57 918 1.74 965 1.9
4,000 648 1.16 704 1.32 758 1.49 809 1.65 858 1.82 905 1.99 951 2.17 995 2.35
4,500 709 1.59 760 1.77 810 1.95 857 2.13 902 2.32 946 2.51 989 2.7 1031 2.9
5,000 774 2.12 821 2.32 866 2.52 909 2.72 952 2.92 993 3.13 1033 3.34 1072 3.55
5,500 836 2.75 880 2.97 921 3.19 962 3.41 1002 3.63 1040 3.85 1078 4.08 1115 4.31
EC120 HZ
2,500 679 0.48 770 0.61 854 0.75
3,000 639 0.54 729 0.68 811 0.82 889 0.97 962 1.13 1031 1.3 1097 1.48
3,500 713 0.8 793 0.95 867 1.11 938 1.28 1005 1.46 1069 1.64 1131 1.83 1191 2.03
4,000 784 1.12 856 1.29 924 1.47 989 1.66 1052 1.85 1111 2.05 1169 2.25 1225 2.46
4,500 857 1.51 923 1.71 985 1.91 1045 2.11 1103 2.32 1159 2.54 1213 2.76 1266 2.98
5,000 934 2.01 994 2.23 1052 2.45 1107 2.67 1161 2.9 1213 3.13 1264 3.37 1314 3.61
5,500 1009 2.60 1064 2.84 1118 3.08 1169 3.32 1220 3.56 1269 3.81 1317 4.07 1363 4.33
EC150
3,500 617 0.89 677 1.03 735 1.18 789 1.33 841 1.48 891 1.64 939 1.81
4,000 606 1.05 665 1.21 721 1.37 773 1.53 824 1.70 872 1.87 919 2.05 964 2.23
4,500 663 1.44 717 1.62 768 1.80 817 1.98 864 2.16 909 2.35 953 2.54 995 2.73
5,000 722 1.92 771 2.11 818 2.31 864 2.51 907 2.71 950 2.91 991 3.12 1031 3.33
5,500 780 2.48 825 2.70 869 2.91 911 3.13 952 3.35 992 3.57 1031 3.79 1069 4.02
6,000 841 3.17 883 3.40 924 3.64 963 3.88 1002 4.11 1039 4.35 1076 4.59 1111 4.84
6,500 901 3.96 940 4.22 978 4.47 1015 4.73 1051 4.98 1087 5.24 1121 5.5 1155 5.76
EC151
3,500 617 0.89 677 1.03 735 1.18 789 1.33 841 1.48 891 1.64 939 1.81
4,000 606 1.05 665 1.21 721 1.37 773 1.53 824 1.70 872 1.87 919 2.05 964 2.23
4,500 663 1.44 717 1.62 768 1.80 817 1.98 864 2.16 909 2.35 953 2.54 995 2.73
5,000 722 1.92 771 2.11 818 2.31 864 2.51 907 2.71 950 2.91 991 3.12 1031 3.33
5,500 780 2.48 825 2.70 869 2.91 911 3.13 952 3.35 992 3.57 1031 3.79 1069 4.02
6,000 841 3.17 883 3.40 924 3.64 963 3.88 1002 4.11 1039 4.35 1076 4.59 1111 4.84
6,500 901 3.96 940 4.22 978 4.47 1015 4.73 1051 4.98 1087 5.24 1121 5.5 1155 5.76
