19.2 Operating Temperatures and Pressures Table
Operating Temperatures and Pressures
Model
Entering
Water Temp.
(°F)
Water
Flow
(GPM/Ton)
Cooling Heating
Suction
Pressure
(PSIG)
Discharge
Pressure (PSIG)
Water Temp.
Rise (°F)
Air Temp.
Drop (°F)
Suction
Pressure
(PSIG)
Discharge
Pressure (PSIG)
Water Temp.
Drop (°F)
Air Temp.
Rise
(°F)
EC072
30°
10.0
— — — — 53–68 229–291 7–8 19–22
16.0
— — — — 56–72 232–297 5–6 21–24
40°
10.0
102–129 162–203 17–21 19–23 62–80 239–305 8–10 22–26
16.0
101–127 146–183 11–14 19–23 67–86 243–312 5–6 23–27
50°
10.0
103–131 186–235 18–21 19–23 74–95 251–321 9–11 24–28
16.0
103–129 169–214 11–13 18–23 79–102 256–329 6–8 26–30
60°
10.0
105–133 213–271 17–20 18–22 86–110 264–338 11–13 27–32
16.0
105–132 195–247 11–13 18–22 93–120 271–348 7–9 29–34
70°
10.0
108–136 243–310 17–21 19–22 100–127 279–357 12–15 31–36
16.0
107–134 225–285 11–13 19–22 109–139 288–368 8–10 33–38
80°
10.0
109–138 277–352 17–21 18–22 116–147 296–377 14–17 34–39
16.0
108–136 259–327 11–13 18–22 127–161 307–392 9–11 36–42
90°
10.0
111–140 316–400 17–20 18–21 134–168 314–399 16–19 38–44
16.0
111–139 297–373 11–13 18–21 147–185 328–416 10–13 40–47
100°
10.0
114–143 359–450 17–20 17–21 — — — —
16.0
113–141 340–423 10–12 17–21 — — — —
EC096
30°
13.0
— — — — 59–74 257–322 8–9 24–28
22.0
— — — — 61–78 260–327 5–6 25–29
40°
13.0
98–123 177–212 17–20 20–25 69–88 271–341 10–11 26–31
22.0
97–121 157–190 10–12 20–25 74–94 276–347 6–7 28–33
50°
13.0
99–125 203–245 17–20 20–25 82–105 286–360 11–13 29–35
22.0
99–123 181–221 9–12 20–25 88–112 294–369 7–8 31–37
60°
13.0
101–128 230–281 17–20 20–25 96–122 304–382 12–14 33–40
22.0
97–122 166–214 10–12 20–25 104–132 314–394 8–9 35–42
70°
13.0
99–126 203–262 17–19 20–25 111–141 324–406 13–16 36–44
22.0
99–125 194–250 10–12 20–25 121–153 337–421 9–10 39–47
80°
13.0
105–132 295–362 16–19 19–23 129–162 346–433 16–18 40–48
22.0
104–131 274–337 9–11 19–24 142–177 364–452 10–11 43–52
90°
13.0
106–135 334–409 15–18 19–24 148–185 372–463 17–20 44–53
22.0
106–133 313–385 10–11 19–24 165–204 395–488 11–13 47–57
100°
13.0
108–137 376–459 15–17 19–23 — — — —
22.0
108–135 357–436 9–11 19–23 — — — —
