Specification Tables
Operating Temperatures and Pressures
Model
Entering
Water Temp.
(°F)
Water
Flow
(GPM)
Cooling Heating
Suction
Pressure
(PSIG)
Discharge
Pressure (PSIG)
Water Temp.
Rise (°F)
Air Temp.
Drop (°F)
Suction
Pressure
(PSIG)
Discharge
Pressure
(PSIG)
Water Temp.
Drop (°F)
Air Temp.
Rise
(°F)
EC120
30°
16.0
— — — — 56–72 257–316 9–10 21–24
32.0
— — — — 59–76 261–322 4–5 22–25
40°
16.0
96–122 168–210 19–22 19–23 67–86 271–333 10–11 24–28
32.0
94–119 147–186 10–11 18–23 72–92 276–340 5–6 25–29
50°
16.0
97–125 192–241 18–21 19–22 72–108 286–351 12–13 27–31
32.0
96–123 170–216 10–11 19–23 78–116 295–361 6–7 29–33
60°
16.0
98–127 220–276 18–21 18–22 94–118 304–372 13–15 30–35
32.0
97–125 197–250 9–10 19–23 102–128 315–384 7–8 31–37
70°
16.0
100–130 252–315 18–21 19–22 109–137 324–395 15–17 33–39
32.0
99–127 228–288 9–11 18–22 121–149 340–413 8–10 35–41
80°
16.0
101–132 288–359 18–21 18–22 126–156 348–422 17–19 37–43
32.0
101–131 263–330 9–11 18–22 142–173 367–443 9–11 39–46
90°
16.0
103–135 327–407 18–21 18–21 146–178 372–449 19–21 40–47
32.0
102–133 301–377 9–11 18–22 165–199 396–475 10–12 44–51
100°
16.0
105–138 370–460 18–20 17–21 — — — —
32.0
105–136 345–429 9–11 17–21 — — — —
EC150
30°
22.0
— — — — 52–68 231–286 6–7 18–20
38.0
— — — — 56–73 235–290 4–5 18–21
40°
22.0
105–132 176–217 15–19 18–22 63–82 241–298 8–9 20–23
38.0
105–131 161–199 9–11 18–22 68–88 245–304 5–5 21–24
50°
22.0
106–135 202–249 14–18 18–22 68–105 253–313 9–10 23–26
38.0
106–134 185–229 9–11 18–23 74–112 258–319 5–6 24–28
60°
22.0
107–137 230–284 15–18 18–22 90–115 266–328 10–11 25–29
38.0
107–136 213–264 8–10 18–22 97–123 273–337 6–7 27–31
70°
22.0
106–137 208–269 15–18 18–22 105–133 281–347 12–13 29–33
38.0
108–138 244–302 8–10 18–22 115–144 290–357 7–8 30–35
80°
22.0
109–142 297–365 14–17 18–21 123–153 299–367 14–15 32–37
38.0
109–140 280–345 8–10 17–21 135–167 311–381 8–9 33–39
90°
22.0
111–144 336–413 14–17 17–20 143–176 319–390 15–17 35–40
38.0
110–142 318–391 9–10 17–21 157–192 334–407 10–11 38–44
100°
22.0
112–146 377–465 14–17 17–20 — — — —
38.0
112–145 360–442 9–10 16–20 — — — —
