19.3 Water-Side Pressure Drop Table
Model
Water Flow
Rate (GPM)
Water-Side Pressure Drop (PSIG)
Water-Side Pressure Drop (Ft of H
2
O)
EC072
10 2.6 6.0
12 3.6 8.3
14 4.8 11.0
16 6.1 14.0
18 7.5 17.3
EC096
12 2.5 5.7
14 3.3 7.5
18 5.1 11.8
21 6.8 15.6
24 8.6 19.8
EC120
16 2.1 4.9
20 3.1 7.3
24 4.4 10.1
28 5.8 13.3
32 7.3 16.9
EC150
20 1.4 3.3
25 2.1 4.9
30 3.0 6.8
35 3.9 9.0
50 7.4 17.1
EC151
20 1.4 3.3
25 2.1 4.9
30 3.0 6.8
35 3.9 9.0
50 7.4 17.1
EC180
22 1.7 3.9
27 2.5 5.7
32 3.3 7.7
42 5.4 12.5
52 8.0 18.4
EC181
22 1.7 3.9
27 2.5 5.7
32 3.3 7.7
42 5.4 12.5
52 8.0 18.4
EC210
30 2.6 5.9
40 4.3 9.9
50 6.4 14.9
60 8.9 20.6
70 11.8 27.2
