Bosch EC Series - Page 54

Specification Tables
Table 15 Operating Temperatures and Pressures Table
Operating Temperatures and Pressures
Model
Entering
Water Temp.
(°F)
Water
Flow
(GPM)
Cooling Heating
Suction
Pressure (PSIG)
Discharge
Pressure (PSIG)
Water Temp.
Rise (°F)
Air Temp.
Drop (°F)
Suction
Pressure
(PSIG)
Discharge
Pressure (PSIG)
Water
Temp. Drop
(°F)
Air Temp.
Rise
(°F)
EC300
30°
45.0
— — — — 55–71 263–320 7–9 22–26
75.0
— — — — 57–73 266–324 4–5 22–27
40°
45.0
89–115 124–170 15–19 18–23 66–84 277–339 9–10 25–29
75.0
89–114 119–162 10–13 18–23 69–88 281–344 5–6 25–30
50°
45.0
92–119 148–202 15–18 17–22 79–100 294–360 10–11 28–33
75.0
91–117 142–192 9–12 17–22 83–105 299–367 6–7 28–34
60°
45.0
95–122 173–234 15–18 18–22 95–118 314–385 11–13 30–36
75.0
94–121 166–223 9–11 18–22 99–124 320–393 7–8 32–38
70°
45.0
96–124 200–269 15–18 17–22 111–138 337–413 13–15 34–40
75.0
96–123 193–257 8–11 17–22 117–145 345–423 8–9 35–42
80°
45.0
98–126 232–308 14–17 17–21 131–160 362–442 14–17 38–45
75.0
98–126 224–295 9–11 17–22 138–169 370–453 8–10 39–46
90°
45.0
100–129 267–350 14–17 17–21 154–186 390–476 15–18 42–50
75.0
100–128 258–336 8–10 17–21 161–195 400–487 9–11 43–51
100°
45.0
102–132 307–398 13–16 16–20 — — — —
75.0
102–131 297–382 8–10 16–20 — — — —
EC360
40°
45.0
89–115 124–170 15–19 18–23 66–84 277–339 9–10 25–29
75.0
89–114 119–162 10–13 18–23 69–88 281–344 5–6 25–30
50°
45.0
92–119 148–202 15–18 17–22 79–100 294–360 10–11 28–33
75.0
91–117 142–192 9–12 17–22 83–105 299–367 6–7 28–34
60°
45.0
95–122 173–234 15–18 18–22 95–118 314–385 11–13 30–36
75.0
94–121 166–223 9–11 18–22 99–124 320–393 7–8 32–38
70°
45.0
96–124 200–269 15–18 17–22 111–138 337–413 13–15 34–40
75.0
96–123 193–257 8–11 17–22 117–145 345–423 8–9 35–42
80°
45.0
98–126 232–308 14–17 17–21 131–160 362–442 14–17 38–45
75.0
98–126 224–295 9–11 17–22 138–169 370–453 8–10 39–46
90°
45.0
100–129 267–350 14–17 17–21 154–186 390–476 15–18 42–50
75.0
100–128 258–336 8–10 17–21 161–195 400–487 9–11 43–51
100°
45.0
102–132 307–398 13–16 16–20 — — — —
75.0
102–131 297–382 8–10 16–20 — — — —
54 |
EC Series Heat Pumps — 8733841499 (2024/05)
