Specification Tables
Operating Temperatures and Pressures
Model
Entering
Water Temp.
(°F)
Water
Flow
(GPM)
Cooling Heating
Suction
Pressure (PSIG)
Discharge
Pressure (PSIG)
Water Temp.
Rise (°F)
Air Temp.
Drop (°F)
Suction
Pressure
(PSIG)
Discharge
Pressure (PSIG)
Water
Temp. Drop
(°F)
Air Temp.
Rise
(°F)
EC240
30°
32.0
— — — — 59–75 301–358 8–10 22–26
64.0
— — — — 62–78 266–324 4–5 22–27
40°
32.0
100–125 166–204 17–21 18–22 69–87 284–346 10–11 24–28
64.0
98–122 145–180 9–11 18–22 74–93 273–336 5–6 25–30
50°
32.0
98–124 150–196 17–21 18–22 81–102 282–348 11–12 27–32
64.0
100–125 169–212 9–11 17–22 88–110 290–358 6–7 28–34
60°
32.0
100–127 176–229 16–20 17–22 96–119 298–369 13–15 30–36
64.0
100–125 165–215 8–11 18–22 105–130 308–381 7–8 32–38
70°
32.0
102–129 204–265 16–20 18–22 112–139 318–394 14–16 33–39
64.0
101–127 193–250 8–11 18–22 124–152 332–410 8–9 35–42
80°
32.0
106–134 287–356 17–21 17–21 131–160 341–421 15–18 37–44
64.0
106–132 263–327 8–10 17–21 145–176 359–442 8–10 40–47
90°
32.0
108–136 327–403 16–20 17–21 152–184 366–452 17–20 40–48
64.0
107–134 303–374 8–10 17–21 169–203 388–475 9–11 44–52
100°
32.0
110–139 372–456 17–20 16–20 — — — —
64.0
110–137 347–426 8–10 16–20 — — — —
EC242
30°
32.0
— — — — 59–75 301–358 8–10 22–26
64.0
— — — — 62–78 266–324 4–5 22–27
40°
32.0
100–125 166–204 17–21 18–22 69–87 284–346 10–11 24–28
64.0
98–122 145–180 9–11 18–22 74–93 273–336 5–6 25–30
50°
32.0
98–124 150–196 17–21 18–22 81–102 282–348 11–12 27–32
64.0
100–125 169–212 9–11 17–22 88–110 290–358 6–7 28–34
60°
32.0
100–127 176–229 16–20 17–22 96–119 298–369 13–15 30–36
64.0
100–125 165–215 8–11 18–22 105–130 308–381 7–8 32–38
70°
32.0
102–129 204–265 16–20 18–22 112–139 318–394 14–16 33–39
64.0
101–127 193–250 8–11 18–22 124–152 332–410 8–9 35–42
80°
32.0
106–134 287–356 17–21 17–21 131–160 341–421 15–18 37–44
64.0
106–132 263–327 8–10 17–21 145–176 359–442 8–10 40–47
90°
32.0
108–136 327–403 16–20 17–21 152–184 366–452 17–20 40–48
64.0
107–134 303–374 8–10 17–21 169–203 388–475 9–11 44–52
100°
32.0
110–139 372–456 17–20 16–20 — — — —
64.0
110–137 347–426 8–10 16–20 — — — —
