Specification Tables
Operating Temperatures and Pressures
Model
Entering
Water Temp.
(°F)
Water
Flow
(GPM)
Cooling Heating
Suction
Pressure (PSIG)
Discharge
Pressure (PSIG)
Water Temp.
Rise (°F)
Air Temp.
Drop (°F)
Suction
Pressure
(PSIG)
Discharge
Pressure (PSIG)
Water
Temp. Drop
(°F)
Air Temp.
Rise
(°F)
EC181
30°
25.0
— — — — 51–65 229–284 6–7 16–19
45.0
— — — — 55–70 232–289 3–4 17–20
40°
25.0
105–130 181–222 15–19 17–21 61–77 238–296 7–9 18–22
45.0
104–127 164–202 8–10 17–22 66–83 243–303 4–5 19–24
50°
25.0
106–132 206–253 14–18 17–21 67–98 249–310 8–10 21–25
45.0
105–130 189–233 8–10 17–21 73–106 255–317 4–6 22–27
60°
25.0
107–134 235–289 14–18 17–21 86–107 262–325 9–11 23–28
45.0
106–132 216–267 8–10 16–21 94–116 270–335 5–7 25–30
70°
25.0
105–133 211–272 14–18 17–21 101–125 277–343 11–13 26–31
45.0
107–134 248–306 8–10 17–21 111–136 288–356 6–8 28–34
80°
25.0
109–138 303–371 14–18 16–20 118–144 295–364 12–15 29–35
45.0
109–137 283–348 8–10 16–20 130–158 308–379 7–9 31–37
90°
25.0
110–140 341–418 14–17 16–19 136–165 314–386 13–16 32–39
45.0
110–139 322–395 7–10 16–20 152–182 330–404 8–10 35–42
100°
25.0
111–142 383–471 14–18 15–19 — — — —
45.0
111–141 365–447 8–10 16–20 — — — —
EC210
30°
28.0
— — — — 56–72 236–298 8–9 21–25
52.0
— — — — 73–90 288–351 1–2 24–28
40°
28.0
95–121 123–166 18–22 19–23 70–88 270–335 9–11 24–28
52.0
94–119 115–156 10–12 20–24 81–101 287–353 2–3 26–30
50°
28.0
97–125 148–198 17–21 19–23 76–111 304–382 11–13 26–31
52.0
96–123 139–186 10–12 18–23 82–119 286–356 6–7 28–33
60°
28.0
100–129 172–229 17–21 18–22 97–121 290–361 12–15 30–35
52.0
99–127 162–216 9–11 18–22 106–131 299–371 7–9 32–37
70°
28.0
103–133 200–264 15–20 18–22 113–140 307–381 13–16 33–39
52.0
102–131 190–251 9–11 18–22 125–153 320–396 8–10 35–40
80°
28.0
105–136 232–305 15–19 18–21 131–161 326–403 16–19 36–43
52.0
104–134 220–289 8–11 17–21 146–177 342–422 9–11 38–45
90°
28.0
106–138 267–349 15–19 17–21 151–183 348–428 18–21 39–46
52.0
106–137 255–332 8–11 17–21 169–203 368–450 10–12 42–49
100°
28.0
108–142 305–398 14–19 17–20 — — — —
52.0
108–140 293–379 7–10 17–21 — — — —
