Bosch FPA-5000 Wiring Guide

DS 10
PE
L --
L +
DS 10
PE
L --
L +
DS 10
PE
L --
L +
NZM 0002 A
OUT1 IN1 OUT2 IN2
B A B A B A B A
DC BAT
–
+
–
+
GND
OUT
GND
IN
SYNC
–
+
-- U+U
24 V -- 28 V
DS 10
i
I ≤ 3000mA
max. 7 x DS 10
EN54-13
Modular Fire Panel Wiring | en 119
Bosch Sicherheitssysteme GmbH Wiring Guide 2016.07 | 12.6 | F.01U.009.201

Bosch FPA-5000 Specifications

General

Max Number of Detectors per Loop	254
Display	LCD
Network Capability	Yes
Power Supply	24 V DC
Operating Temperature	-5°C to +50°C
Communication Ports	Ethernet
Humidity Range	95% non-condensing
