Bosch FPA-5000 Wiring Guide

Table of contents
1
History 5
1.1 12.0 -> 12.1 5
1.2 12.1 -> 12.2 6
1.3 12.2 -> 12.3 8
1.4 12.3 -> 12.4 9
1.5 12.4 -> 12.5 10
1.6 12.5 -> 12.6 11
2
Notes 12
2.1 Content 12
2.2 Product Information 12
2.3 Important Notes 12
2.4 User Notes 12
2.4.1 Chapter Symbols 15
2.4.2 Connection Symbols 15
2.4.3 Power Supply and Wiring 16
2.5 Resistance Values 17
3
Wiring 18
3.1 Networking 19
3.1.1 Printer 27
3.1.2 Transmission units 28
3.1.3 FPE-5000-UGM 30
3.2 Power Supply 32
3.3 Operating and display panels 34
3.4 EN 54‑13 36
3.4.1 LSN 0300 A (EN 54-13) 37
3.4.2 CZM 0004 A (EN 54-13) 100
3.4.3 NZM 0002 A 118
3.4.4 IOS 0020 A 125
3.4.5 FPE-5000-UGM 127
3.4.6 FMF-ADP-FBF/FMF-ADP-TTY 128
3.4.7 FLM-420/4-CON-S/D 130
3.4.8 FLM-420-NAC-D 150
3.5 DIBT / Detector Bases 157
3.6 Functional Modules 180
3.6.1 BCM-0000-B 181
3.6.2 CZM 0004 A 182
3.6.3 ENO 0000 A/B 204
3.6.4 LSN 0300 A 211
3.6.5 NZM 0002 A 246
3.6.6 RMH 0002 A 257
3.6.7 IOS 0020 A 261
3.6.8 FPE-5000-UGM 274
3.7 Interface Modules 278
3.7.1 FLM-420/4-CON-D/S 279
3.7.2 FLM-420-NAC-D/S 303
3.7.3 FLM-420-RLE-S 310
3.7.4 FLM-420-RLV1-E 311
Modular Fire Panel Table of Contents | en 3
Bosch Sicherheitssysteme GmbH Wiring Guide 2016.07 | 12.6 | F.01U.009.201

Bosch FPA-5000 Specifications

General

Max Number of Detectors per Loop	254
Display	LCD
Network Capability	Yes
Power Supply	24 V DC
Operating Temperature	-5°C to +50°C
Communication Ports	Ethernet
Humidity Range	95% non-condensing
