BCM-0000-B
FPP--5000
12 V 12 V
BCM-0000-B
+ - + -
24V 24V
MAIN BAT1 BAT2 FAULT
FAULT
AC
BAT
MAIN POWER
MAIN POWER
TROUBLE
TROUBLE
TROUBLE
BATTERY 1
BATTERY 2
+ - + - + - - - - +
S
1 2
FLM--420--NAC--D
IN OUT
LSN FAIL
a1- b1+ a2- b2+ ac bat
b a b a 0V 24V
24V
FLM-420-NAC-D
-
+
3k9/2k2
3.6.1
Modular Fire Panel Wiring | en 181
Bosch Sicherheitssysteme GmbH Wiring Guide 2016.07 | 12.6 | F.01U.009.201
