Bosch FPA-5000 Wiring Guide

FLM-420-NAC-D
DS 10
PE
L --
L +
FLM--420--NAC--D
IN OUT
LSN FAIL
a1- b1+ a2- b2+ ac bat
b a b a 0V 24V
--U+U
24 V -- 28 V
DS 10
EN54-13
3.4.8
150 en | Wiring Modular Fire Panel
2016.07 | 12.6 | F.01U.009.201 Wiring Guide Bosch Sicherheitssysteme GmbH

Bosch FPA-5000 Specifications

General

Max Number of Detectors per Loop	254
Display	LCD
Network Capability	Yes
Power Supply	24 V DC
Operating Temperature	-5°C to +50°C
Communication Ports	Ethernet
Humidity Range	95% non-condensing
