Bosch FPA-5000 - Page 223

BCM-0000-B
+ - + -
24V 24V
MAIN BAT1 BAT2 FAULT
FAULT
AC
BAT
MAIN POWER
MAIN POWER
TROUBLE
TROUBLE
TROUBLE
BATTERY 1
BATTERY 2
+ - + - + - - - - +
S
1 2
LSN 0300 A
AUX1 LSN1 AUX2 LSN2
+ – a– b+ + – a– b+
FLM--420--NAC--D
IN OUT
LSN FAIL
a1- b1+ a2- b2+ ac bat
b a b a 0V 24V
+
--
FLM-420-NAC-D/S
24V
Modular Fire Panel Wiring | en 223
Bosch Sicherheitssysteme GmbH Wiring Guide 2016.07 | 12.6 | F.01U.009.201
