Bosch FPA-5000 Wiring Guide

MSS 300-SA
NZM 0002 A
OUT1 IN1 OUT2 IN2
B A B A B A B A
DC BAT
–
+
–
+
GND OUT GND IN
SYNC
–
+
3k92
--U+U
24 V -- 28 V
256 en | Wiring Modular Fire Panel
2016.07 | 12.6 | F.01U.009.201 Wiring Guide Bosch Sicherheitssysteme GmbH

Bosch FPA-5000 Specifications

General

Max Number of Detectors per Loop	254
Display	LCD
Network Capability	Yes
Power Supply	24 V DC
Operating Temperature	-5°C to +50°C
Communication Ports	Ethernet
Humidity Range	95% non-condensing
