Page #280 background imageLoading...
Page #280 background image
0165X9
IR3 Flame Detector
b1+ a- b2+
2+ 1/2- 1+
LSN
AUX
PWR IN
LSN AUX
OUT2/IN1
OUT1
or
EXT.PWR
–
+
–
+
–
+
FLM-420/4-CON-D
2
CONV
3k92
0165X9
+IN -IN
ALARM (NO) FAULT (NC)
max. 1 x 0165X9
0165X9
+IN
-IN
ALARM (NO) FAULT (NC)
0
1
280 en | Wiring Modular Fire Panel
2016.07 | 12.6 | F.01U.009.201 Wiring Guide Bosch Sicherheitssysteme GmbH
