Page #99 background imageLoading...
Page #99 background image
FK 100 LSN
b1 a1 0V +Ub2 a2 0V +U
FK 100 LSN
+U 0V
POW IN
+U 0V
POW OUT
LSN
a1- b1+ a2- b2+ Shield
FLM-420-EOL4W
a
b
+
-
a
b
+
-
D
EN54-13
4
LSN
AUX
Modular Fire Panel Wiring | en 99
Bosch Sicherheitssysteme GmbH Wiring Guide 2016.07 | 12.6 | F.01U.009.201
