English–41 609 929 F69 • (04.10) PS
Symbols specifically for this Machine
SW Spanner width (in mm) Distance between parallel surfaces on fastener el#
ements on which the tool must fit on (e.g. hex nuts
or hex#head screws), fit over (e.g. ring spanner) or
fit in (e.g. socket#head screws).
Left rotation/Right rotation Direction of drive rotation
/ Hex socket drive/Square drive Type of tool holder
Arrow Action in the direction of arrow
Alternating current Type or a characteristic of current
Direct current Type or a characteristic of current
Alternating or direct current Type or a characteristic of current
Class II construction Designates double insulated constructed tools
Protection class I
(Earthing terminal)
Machines of the protection class I must be earthed
Warning symbol Alerts user to warning messages.
Read and understand instructions before opera#
tion
Warning symbol Provides information for correct handling, e.g.,
read the operating instructions.
Symbol Name Meaning
Symbol Meaning
Warning symbol Danger area! Keep fingers, hands or arms away
from these areas.
Warning symbol Wear protective glasses.
Warning symbol Wear hearing protection.
Warning symbol Wear dust protection mask.
Note symbol Observe the dimensions of the saw blade. The
hole diameter must fit the tool spindle without play.
Do not use reducer pieces or adapters.
