32 Setting knob for 33.9° bevel angle (vertical)
33 Multi purpose tool
34 Tightening knob for the length stop 35
35 Length stop
36 Sliding saw table extension
37 Clamping handle for the saw table extension
38 Scale for mitre angle (horizontal)
39 Knob for the setting of the bevel angle range (ver#
tical)
40 Spindle lock
41 Locking lever
**
42 Tool holder
43 Attachment screws for tool holder
44 Attachment nuts for tool holder
45 Open#end spanner (10 mm, 17 mm)
46 Allen key (3 mm)
47 Allen key (1.5 mm)
48 Phillips screw (attachment of the swinging guard)
49 Phillips screw (attachment of the swinging guard)
50 Hex#head bolt for attaching the saw blade
51 Washer
52 Clamping flange
53 Tool spindle
54 Angle adapter for dust bag
55 Sawdust ejector
56 Clamping lever of the quick action clamp
57 Threaded rod of the quick action clamp
58 Holes for quick action clamp
59 Button for quick releasing the adjustment screw of
the depth stop
60 Depth stop
61 Screw for the length stop 35
62 Screws of the table insert
63 – 66
Adjustment bolts for the 0° basic setting (vertical
bevel angle)
67 Adjustment bolt for the 45° basic setting
(left vertical bevel angle)
68 Adjustment bolt for the 45° basic setting
(right vertical bevel angle)
69 Adjustment bolt for the clamping action of the
clamping handle 14
70 Adjustment bolts for the clamping action of the
clamp 3
71 Angle indicator (horizontal)
72 Adjustment screw of the fence extension
73 Hex#head bolts (14 mm) of the fence
0 601 B22 537 (Australia):
* 6 Button for unlocking the On/Off switch 25
** The locking lever 41 is not included.
Perform the operations described in the following
accordingly without the locking lever 41.
Not all the accessories illustrated or described are in
cluded in standard delivery.
4 MOUNTING
Avoid unintentional starting of the electro
tool. During mounting and for all work on
the electrotool itself, the main plug must
not be connected to the power source.
Items Included
Before putting the electro#tool into operation, check
that all of the items listed below have been delivered:
– Dual#bevel slide mitre saw with premounted saw
blade
–Dust bag 1
– Angle adapter 54 for dust bag
–Locking knob 12
– Tool holder 42 with open#ended spanner 45 and
two Allen keys 46, 47
– Multi purpose tool 33 with hex#socket spanner
(14 mm) and screwdriver bit (hex#head 4 mm and
Phillips)
– Quick action clamp 21
Check the electrotool for possible damage.
Before further use of the electro#tool, check that all the
protective devices are fully functional. Any lightly dam#
aged parts must be carefully checked to ensure flaw#
less operation of the tool. All parts must be properly
mounted and all conditions fulfilled that ensure fault#
less operation.
Damaged protective devices and parts must be imme#
diately replaced by an authorised service centre.
Initial Operation
Remove all parts supplied carefully from the packag#
ing.
Remove all packing material from the electro#tool and
the accessories provided.
