Bosch ICP-CC408 - Figure 7: Basic Pager Display

ICP-CC408 | Installation Guide | 10.0 Dialer Reporting Formats EN | 48
Bosch Security Systems, Inc. | 12/08 | F01U089463-02
Figure 7: Basic Pager Display
1 – Subscriber ID number
2 – Zone status
3 – System status
4 – 0 – Zone Normal
1– Alarm
2 – Manually Isolated
5 – 8 – Disarmed
9 – Armed
6 – 0 – Normal
1 – Panic/Duress
2 – Fire Alarm
3 – Medical Alarm
7 – 0 – AC Normal
1 – AC Failure
8 – 0 – System Normal
1 – System Fault
