ICP-CC408 | Installation Guide | 15.0 System Reporting Information EN | 64
Bosch Security Systems, Inc. | 12/08 | F01U089463-02
If Lockout Dialer is enabled for any zone,
the last restore signal is not transmitted
until the system is disarmed.
If the ICP-CC408 Control Panel is
partitioned, the Swinger Shutdown Count
for Dialer applies to both Area 1 and
Area 2.
Example
All eight zones are programmed for lockout dialer
with a Swinger Shutdown Count of 6. If Zone 1
activates an alarm, the Swinger Shutdown Count
decrements to 5 when the control panel calls.
If Zone 1 reactivates the dialer, the Swinger
Shutdown Count is decremented to 4. If Zone 1
reactivates the dialer three more times, the Swinger
Shutdown Count is 1.
If Zone 2 activates an alarm, the Swinger Shutdown
Count is decremented to 0, which locks out Zone 2
from activating the dialer until the system is reset. At
this point, the Swinger Shutdown Count for the
Dialer is reset to 6 and the process of swinger
shutdown for the remaining zones, including Zone 1,
begins again until all zones are locked out.
15.0 System Reporting
Information
This section covers features that are involved with
basic housekeeping of the system. These include
monitoring of the zones, whether they are isolated
from the system, or more importantly that they are
actually operating, the status of both the AC MAINS
and DC power to the system, and codepad-generated
alarms activated by the user.
15.1 Zone Status – Bypass Reports
Location
325 to 326
Location Default
Zone Bypass Report 325 9
Zone Bypass Restore Report 326 8
A zone is bypassed when it is manually isolated.
Refer to Section 4.11 Isolating Zones 4.11 Isolating Zones
on page 23 for information on isolating zones. A
Zone Bypass Report (Contact ID Event Code 570) is
sent at the end of Exit Time for any zone that was
manually isolated. A 24-Hour Zone sends a Zone
Bypass Report when the zone is selected to be
isolated.
A Zone Bypass Restore Report is sent when the
system is disarmed. All bypassed zones are
automatically cleared when the system is disarmed.
The Bypass Code parameter is used as the expansion
digit in 4 + 2 Formats. It has no effect on Contact ID
Format because a Zone Bypass is always reported as
Event Code 570.
If Zone Bypass Reports are not required,
program Locations 325 and 326 as 0.
15.2 Zone Status – Trouble Reports
Location
327 to 328
Location Default
Zone Trouble Report 327 2
Zone Trouble Restore Report 328 3
A zone is in trouble when it is unsealed at the end of
Exit Time. A Sensor Trouble Report (Contact ID
Event Code 380) is sent to indicate that one or more
zones were automatically isolated by the system.
24-Hour Zones that are unsealed at the end of Exit
Time do not transmit a Sensor Trouble Report
because the restore for that zone is still outstanding.
A Sensor Trouble Restore Report is sent for Burglary
Zones when the zone is resealed or the next time the
system is disarmed (whichever happens first). A
24-Hour Zone sends a restore signal only when it is
resealed.
The Trouble code parameter is used as the expansion
digit in 4 + 2 Format. It has no effect on Contact ID
Format because a Sensor Trouble Report is always
reported as Event Code 380.
If Sensor Trouble Reports are not
required, program Locations 327 and 328
as 0.
15.3 Zone Status – Sensor Watch
Reports
Location
329 to 330
Location Default
Sensor Watch Report 329 4
Sensor Watch Restore Report 330 5
A Self Test Failure Report (Contact ID Event Code
307) is sent to the base station receiver when a zone
was not activated during the Sensor Watch Time
programmed in Locations 408 and 409 (refer to
Section 17.7 Sensor Watch Time on page 76). This
report continues to be sent (according to the
frequency of the Sensor Watch Time) until the fault is
corrected.
To clear the fault and stop any additional reporting,
you must unseal and reseal the zone that registered
the fault. Use the Sensor Watch Time in Locations
408 and 409 to set the number of days a zone can
remain sealed without registering a fault. Refer to
Section 14.3.5 Zone Options 1 on page 60 to select
zones to be monitored by the Sensor Watch feature.
If Self Test Failure Reports are not
required, program Locations 329 and 330
as 0.
