14 | Recording
114/148 DDU 9 Bosch Motorsport
14.2.5 Recording diagnosis
The channel ‘statectrl_ok’ of the DDU 9 can be used for online monitoring of recording
status.
Bit Value Name
0 1 RECORD
1 2 DATAOK
2 4 BLKOK
3 8 -
4 16 -
5 32 -
6 64 STARTED
7 128 -
Content of status bits
Name Bitset Bit cleared
RECORD Measurement data is re-
corded.
No measurement data will be stored because meas-
urement thresholds are not reached.
DATAOK Received data without
error.
Discarding received data because of wrong
timestamps. Check wiring of SYNC signal.
BLKOK All measurement blocks
have been set up cor-
rectly.
Some measurement blocks have not been set up
correctly.
STARTED A measurement has
been set up.
A measurement is not set up. Either no recording
configuration has been found or logger software
upgrade is not activated.
14.2.6 Displaying online recording diagnosis
('statectrl_ok')
1. To add a Recording Diagnosis element to a measurement sheet, change to page “Cal-
ibration/Measuring“ and drag a ‘Bit-LED’ element from the Toolbox and drop it on
measurement sheet.
2. Drag channel ‘statectrl_ok’ from the Data Area and drop it on the ‘Bit-LED’ element.
